2.3 Connection and wiring overview
2-47
E Siemens AG 2013 All Rights Reserved
SIMODRIVE POSMO A User Manual (POS1) – 08/2013 Edition
All interfaces, terminals and switches of the SIMODRIVE POSMO A
are listed in the following table with technical information.
Table 2-2 Overview of the interfaces, terminals and switches
No.
De-
sig-
na-
tion
Function Type
1)
Technical specifications Cross–
section
X1
5L+
6L+
Load power supply
+24 V/+48 V
+24 V/+48 V
I/O
I/O
24 V for the 75 W motor
48 V for the 300 W motor
––> Technical data on the power sup-
ply, refer to Chapter 2.6.1 or 2.6.2
Max.
4 mm
2
X2 5M
6M
Ground 24 V/48 V
Ground 24 V/48 V
I/O
I/O
0 V
0 V
4 mm
X3
A1
B1
PROFIBUS–DP bus connection
A cable
B cable
I/O
I/O
–
–
Max.
0.35
mm
2
X4
A2
B2
PROFIBUS–DP bus connection
A cable
B cable
I/O
I/O
–
–
Max.
0.35
mm
2
3L+
3M
Electr. power supply (optional)
+24 V
Ground, 24 V
I/O
I/O
24 V  20 %
Current drain: 250 mA
The electronics can be separately
supplied with 24 V via these terminals.
Advantage: When the load power sup-
ply is shut down, the electronics are
still supplied with power and remain
functional (no galvanic isolation).
Max.
0.75
mm
2
X5
1VS
I/Q1
1M
2VS
I/Q2
2M
P24 output
Input/output terminal 1
M24 output
P24 output
Input/output terminal 2
M24 output
O
I/O
O
O
I/O
O
S Output (terminals Q1 and Q2):
– Maximum current/output:
100 mA
S Supply (terminal VS):
– Max. current/terminal:
100 mA
S Input (terminals I1 and I2):
– Current drain: 15 mA
– 24 V  20 %
The following can be connected:
S BERO (3–wire PNP)
S External relay
S Logical I/Os (PLC)
Max.
0.75
mm
2
4L+
4M
Electr. power supply (optional)
+24 V
Ground, 24 V
I/O
I/O
24 V  20 %
The electronics of an additional unit
can be supplied from these terminals.
Max.
0.75
mm
2
Interfaces,
terminals,
Switch S1
2 Installing and Connecting–Up
02.9908.04
