9.3 Dimension drawing 1F☐2105
The motor has the following dimensions in the following frame sizes:


'௑





%*/%3.


.
LL


L

K
""
"
"







① Option with feather key
Motor frame size Overall length of the motor
without brake with brake
k / mm k1 / mm
1F☐2105-4 173 200
1F☐2105-6 215 242
You will 󹪝nd further dimensions in the dimension drawings in the relevant catalog.
Assembly drawings/dimension sheets
9.3 Dimension drawing 1F☐2105
1FK2 Synchronous Motors for SINAMICS S120
Con󹪝guration Manual, 02/2022, A5E46927724B AD 151
