Motor components
4
4.1 Encoder
Motors with DRIVE-CLiQ interface are designed to operate with the SINAMICS converter system.
Signal transmission to the converter is performed digitally.
The motors have an electronic rating plate that simplies commissioning and diagnostics.
The motor and encoder system are automatically identied and all motor parameters are
automatically set.
You will nd further information in the relevant SINAMICS manual.
NOTICE
Damage to electrostatic sensitive devices
The contacts of the DRIVE-CLiQ interface have direct contact with components that can be
destroyed by electrostatic discharge (ESDS).
• Avoid touching the terminals directly with hands or tools. They may be electrostatically
charged and damage components.
The encoders are suitable for the extended safety functions.
Table 4-1 The 1FK2 can be supplied with the following encoders:
Encoder designation AS22DQC AM22DQC
Description Absolute encoder 22-bit single‐
turn
Absolute encoder 22-bit + 12-bit
multiturn
Identier at the 14th digit of the
article number
S M
Operating voltage 24 V 24 V
Maximum current consumption 70 mA 70 mA
Resolution 4,194,304 = 22 bit 4,194,304 = 22 bit
Absolute position Yes, one revolution Yes, 4096 revolutions (12 bits)
Maximum angular error ± 100 " ± 100 "
1FK2 Synchronous Motors for SINAMICS S120
Conguration Manual, 02/2022, A5E46927724B AD 59
