Siemens SIMOTICS S-1FK2 Configuration Manual

6.2 Motor overview / Assignment Motor modules / Power cables
On the following pages, you can 󹪝nd the suitable SINAMICS Motor Modules and MOTION-
CONNECT power cables for the 1FK2.
You can 󹪝nd more information in the Catalog NC 82 (
https://
support.industry.siemens.com/cs/ww/en/view/109746977).
Example of an Article number (order number) for a SINAMICS Motor Module
The following table describes the options that can be selected for the SINAMICS Motor Module.
Description Position in the article number
1 2 3 4 5 6 7 - 8 9 10 11 12 - 13 14 15 16
SINAMICS Motor Modules S120 Book‐
size (example)
6 S L 3 1 2 0 -
Single Motor Module 1
Double Motor Module 2
T E 2 1 - 0 A D
Version release ☐
SINAMICS Motor Module S120 Booksize type C/D, DC link voltage 510 V to 720 V DC, line voltage,
3 AC 380 V to 480 V
You can 󹪝nd the suitable SINAMICS Motor Modules in the following tables.
Motor data Combination with SINAMICS S120 Booksize type C/D Motor Module
Order number Moment of iner‐
tia
Static torque /
max. torque
Static torque / max. tor‐
que in conjunction with
S120 Booksize type C/D
Article number for S120
Booksize type C/D
Rated current / max. cur‐
rent for S120 Booksize
type C/D
J
mot
/ kg cm² M
0
/M
max
/ Nm M
0
/M
max
/ Nm 6SL3120-... I
max
/ I
N
/ A
High Dynamic
1FK2103-2AH 0.093 0.64 / 1.95 0.64 / 1.95 ...-☐TE13-0AD☐ 3 / 9
1FK2103-4AH 0.14 1.27 / 4.05 1.27 / 4.05 ...-☐TE13-0AD☐ 3 / 9
1FK2104-4AF 0.35 1.27 / 3.75 1.27 / 3.75 ...-☐TE13-0AD☐ 3 / 9
1FK2104-4AK 0.35 1.27 / 3.85 1.27 / 3.85 ...-☐TE13-0AD☐ 3 / 9
1FK2104-5AF 0.56 2.4 / 7.5 2.4 / 7.5 ...-☐TE13-0AD☐ 3 / 9
1FK2104-5AK 0.56 2.4 / 7.6 1.6 / 4.66
2.4 / 7.22
...-☐TE13-0AD☐
...-☐TE15-0AD☐
3 / 9
5 / 15
1FK2104-6AF 0.76 3.2 / 10 3.2 / 8.58
3.2 / 10
...-☐TE13-0AD☐
...-☐TE15-0AD☐
3 / 9
5 / 15
1FK2105-4AF 1.7 5 / 15 3.2 / 8.9
5 / 13.3
5 / 15
...-☐TE13-0AD☐
...-☐TE15-0AD☐
...-☐TE21-0AD☐
3 / 9
5 / 15
9 / 27
1FK2105-6AF 2.7 8 / 24 6 / 16.5
8 / 24
...-☐TE15-0AD☐
...-☐TE21-0AD☐
5 / 15
9 / 27
Technical data and characteristics
6.2 Motor overview / Assignment Motor modules / Power cables
1FK2 Synchronous Motors for SINAMICS S120
Con󹪝guration Manual, 02/2022, A5E46927724B AD 85
