Siemens SIMOTICS S-1FK2 Configuration Manual

The DT CONFIGURATOR supports you when generating plant/system documentation regarding
project-speci󹪝c information.
Note
The 3D model in the DT CONFIGURATOR is a simpli󹪝ed representation that does not show all of
the details.
You can 󹪝nd further information on the Internet at DT CONFIGURATOR (http://siemens.de/dt-
kon󹪝gurator):
Recency of dimensional drawings
Note
Changing motor dimensions
Siemens AG reserves the right to change the dimensions of the motors as part of mechanical
design improvements without prior notice. This means that dimensional drawings can become
out of date.
Current dimensional drawings can be requested free of charge from the sales department of
your local SIEMENS o󹪟ce.
Assembly drawings/dimension sheets
9.7 Dimension drawing 1F☐2210
1FK2 Synchronous Motors for SINAMICS S120
156 Con󹪝guration Manual, 02/2022, A5E46927724B AD
