Motor components and options
4.2 Options
S-1FT7 synchronous motors
Configuration Manual, 09/2018, A5E45099423B AA
103
Options X.., K23, K24, and N16 - Paint finish
Paint finish
If no special color is selected, 1FT7 type series motors are painted in the standard color
pearl dark gray (RAL 9023).
Figure 4-19 1FT7 standard color
The 1FT7 servomotor can be supplied in various colors.
You can select between optional colors and special colors.
All finishes meet the requirements for environmental conditions of climate class 3K4
according to IEC 60721-3-3 with the exception of the environmental influencing variables
"low air temperature", "condensation" and "low air pressure".
Note
Additional information is provided in Chapter "
Environmental conditions (Page 30)".
Additional data relating to en
vironmental conditions for "Transporting (Page 361)" and
Storage (Page 365)" of the motors is provided in the appropriate chapters in this
The optional colors are available in the standard delivery time.
Special colors may increase the delivery time.
RAL 9005, jet black X01
RAL 9001, cream white X02
RAL 6011, reseda green X03
RAL 7032, pebble gray X04
RAL 5015, sky blue X05
RAL 1015, light ivory X06
RAL 7016, anthracite gray X09
