Siemens SIMOTICS S-1FT7 User Manual

Technical data and characteristic curves
6.3 Data sheets and characteristics
S-1FT7 synchronous motors
268 Configuration Manual, 09/2018, A5E45099423B AA
6.3.3
1FT7 Compact - water cooling
6.3.3.1
1FT7062-_W
Three-phase servomotor 1FT7062-5WF7
Technical specifications
Symbol
Unit
Value
Configuration data:
Rated speed
n
N
rpm
3000
Rated torque (100K)
M
N(100K)
Nm
10.0
Rated current (100K)
I
N(100K)
A
7.8
Static torque (100K)
M
0(100K)
Nm
10.0
Stall current (100K)
I
0(100K)
A
7.4
Static torque (60K)
M
0(60K)
Nm
8.0
Stall current (60K)
I
0(60K)
A
5.9
Optimum operating point:
Optimum speed
n
opt
rpm
3000
Optimum power
P
opt
kW
3.14
Limiting data:
Max. permissible speed (mech.)
n
max mech
rpm
9000
Maximum torque M
max
Nm 26.0
Maximum current
I
max
A
27.2
Motor data:
No. of poles
2p
10
Torque constant (100K)
k
T
Nm/A
1.35
Voltage constant (at 20 °C)
k
E
V/1000 rpm
85.5
Winding resistance (at 20 °C)
R
Str
W
1.0
Rotating field inductance
L
D
mH
9.1
Electrical time constant
T
el
ms
9
Mechanical time constant
T
mech
ms
1.3
Thermal time constant
T
th
min
1.5
Moment of inertia
J
mot
kgm
2 ,
10
-4
8.1
Shaft torsional stiffness
c
t
Nm/rad
39500
Weight
m
mot
kg
11.0
Motor data with integrated brake:
Moment of inertia (with brake)
J
mot
kgm
2 ,
10
-4
10.6
Shaft torsional stiffness (with brake)
c
t
Nm/rad
28500
Weight (with brake)
m
Mot
kg
12.2
Data with SINAMICS S120 Booksize / S120 Booksize Compact
Rated converter current I
N Inv
A 9
Maximum converter current
I
max Inv
A
27
Max. torque (converter operation)
M
max Inv
Nm
26
Max. permissible speed (converter operation)
n
max Inv
rpm
6700
The rated data are valid for a 600 V DC-link voltage
