Motor components and options
4.2 Options
S-1FT7 synchronous motors
Configuration Manual, 09/2018, A5E45099423B AA
91
4.2.4.5
Option L06 - increased shock loads
Option L06 - increased shock loads
Option L06 can be ordered for motors 1FT7117. The motors are designed for operation
under high shock loads in accordance with DIN ISO 10816-1.
Option L06 cannot be combined with option L03 "increased vibration stress".
The following motors are available with option L06:
● 1FT7117-7SC71-☐L☐0-Z L06 (force-ventilated 2000 rpm)
● 1FT7117-7SF71-☐L☐0-Z L06 (force-ventilated 3000 rpm)
● 1FT7117-7AC71-☐L☐0-Z L06 (naturally cooled 2000 rpm)
● 1FT7117-7AF71-☐L☐0-Z L06 (naturally cooled 3000 rpm)
Technical specifications
Version
M
0
M
N
M
max
1FT7117-7SC71-☐L☐0-Z L06 Q4☐
1)
105 Nm
82 Nm (2000 rpm)
290 Nm
1FT7117-7SF71-☐L☐0-Z L06 Q4☐
1)
105 Nm
54 Nm (3000 rpm)
290 Nm
1FT7117-7AC71-☐L☐0-Z L06
81 Nm
55 Nm (2000 rpm)
290 Nm
1FT7117-7AF71-☐L☐0-Z L06 81 Nm 30 Nm (3000 rpm) 290 Nm
1) Selectable outlet direction of the fan connector:
Table 4- 6 Outlet directions of the fixed fan connector
Q41
Transverse right
Q43
Axial NDE
Q42
Transverse left
Q44
Axial DE
Shock loads in operation acc. to DIN ISO 10816-1
Radial acceleration of 250 m/s² during a period of 10
7
shocks radial.
Noise emission
Measuring-surface sound pressure level L p(A) < 80 dB (A) (speed range from 0 to rated
speed)
See also
Sales and delivery release SIMOTICS S-1FT7117
(
https://support.industry.siemens.com/cs/document/109742370/release-for-sales-and-
delivery-simotics-s-1ft7117-(shaft-height-100-high-dynamic)?dti=0&lc=en-WW)
