Siemens SIMOTICS S-1FT7 User Manual

Technical data and characteristic curves
6.2 Motor overview / assignment of Motor Modules / power cables
S-1FT7 synchronous motors
Configuration Manual, 09/2018, A5E45099423B AA
147
Table 6- 8 1FT7 Compact water cooling
Motor
Converter: SINAMICS S120 Booksize
Power cable
Order number
M
0 (100K)
/ Nm
Connector size
5)
/
Cable cross-
section
4)
Order number
2)
Base load
current
I
H
/ A
M
max (100K) Inv
1)
/
Nm
Order number
3)
1FT7062-5WF7 10 1 / 4 x 1.5 6SL3120-1TE21-
0AD❑
9 26.0 6FX❑002-5❑N06-
❑❑❑❑
1FT7062-5WK7 10 1 / 4 x 1.5 6SL3120-1TE21-
8AD❑
18 26.0 6FX❑002-5❑N06-
❑❑❑❑
1FT7064-5WF7 16 1 / 4 x 1.5 6SL3120-1TE21-
8AD❑
18 40.0 6FX❑002-5❑N06-
❑❑❑❑
1FT7064-5WK7 16 1 / 4 x 2.5 6SL3120-1TE23-
0AD❑
30 40.0 6FX❑002-5❑N16-
❑❑❑❑
1FT7066-5WF7 20 1 / 4 x 1.5 6SL3120-1TE21-
8AD❑
18 55.0 6FX❑002-5❑N06-
❑❑❑❑
1FT7066-5WH7 20 1 / 4 x 2.5 6SL3120-1TE23-
0AD❑
30 55.0 6FX❑002-5❑N16-
❑❑❑❑
1FT7068-5WF7 30 1 / 4 x 2.5 6SL3120-1TE23-
0AD❑
18 68.5 6FX❑002-5❑N16-
❑❑❑❑
1FT7082-5WC7 21 1.5 / 4 x 1.5 6SL3120-1TE23-
0AD❑
18 55.0 6FX❑002-5❑N26-
❑❑❑❑
1FT7082-5WF7 21 1.5 / 4 x 2.5 6SL3120-1TE23-
0AD❑
18 55.0 6FX❑002-5❑N36-
❑❑❑❑
1FT7082-5WH7 21 1.5 / 4 x 4 6SL3120-1TE23-
0AD❑
30 55.0 6FX❑002-5❑N46-
❑❑❑❑
1FT7084-5WC7 35 1.5 / 4 x 2.5 6SL3120-1TE24-
5AA❑
18 87.0 6FX❑002-5❑N36-
❑❑❑❑
1FT7084-5WF7 35 1.5 / 4 x 4 6SL3120-1TE24-
5AA❑
30 90.0 6FX❑002-5❑N46-
❑❑❑❑
1FT7084-5WH7 35 1.5 / 4 x 6 6SL3120-1TE24-
5AA❑
45 71.0 6FX❑002-5❑N54-
❑❑❑❑
1FT7086-5WC7 50 1.5 / 4 x 4 6SL3120-1TE26-
0AA❑
30 125.0 6FX❑002-5❑N46-
❑❑❑❑
1FT7086-5WF7 50 1.5 / 4 x 6 6SL3120-1TE26-
0AA❑
45 102.0 6FX❑002-5❑N54-
❑❑❑❑
1FT7086-5WH7 50 1.5 / 4 x 10 6SL3120-1TE26-
0AA❑
45 88.0 6FX❑002-5❑N64-
❑❑❑❑
1FT7102-5WB7 50 1.5 / 4 x 2.5 6SL3120-1TE21-
8AD❑
18 125.0 6FX❑002-5❑N36-
❑❑❑❑
1FT7102-5WC7 50 1.5 / 4 x 4 6SL3120-1TE23-
0AD❑
30 130.0 6FX❑002-5❑N46-
❑❑❑❑
1FT7102-5WF7 50 1.5 / 4 x 10 6SL3120-1TE24-
5AA❑
45 89.5 6FX❑002-5❑N64-
❑❑❑❑
1FT7105-5WB7 90 1.5 / 4 x 6 6SL3120-1TE23-
0AD❑
30 230.0 6FX❑002-5❑N56-
❑❑❑❑
1FT7105-5WC7 90 1.5 / 4 x 10 6SL3120-1TE24-
5AA❑
45 167.5 6FX❑002-5❑N64-
❑❑❑❑
1FT7105-5WF7 90 3 / 4 x 16 6SL3120-1TE26-
0AA❑
60 161.0 6FX❑002-5❑S23-
❑❑❑❑
1FT7108-5WB7 125 1.5 / 4 x 10 6SL3120-1TE24-
5AA❑
45 249.5 6FX❑002-5❑N64-
❑❑❑❑
