Description of the motors
2.5 Selection based on the article number
S-1FT7 synchronous motors
Configuration Manual, 09/2018, A5E45099423B AA
35
Description
Position of the article number
1
2
3
4
5
6
7
-
8
9
10
11
12
-
13
14
15
16
-
Z
Sealing air connection
Q12
Encoder sealing
Q13
Connector outlet directions for fixed ventilation connectors with 1FT7117 force-
ventilated
Q41...Q44
Customer data on the rating plate
Y84
Special paint finish for environmental conditions according to climate group 3K4, pri-
mer and paint finish in anthracite gray, RAL 7016
K23
Special paint finish for environmental conditions according to climate group 3K4, pri-
mer and additional paint finish
K23+
X..
Primed (unpainted)
K24
Paint finish
6)
jet black, matt
RAL 9005
X01
cream
RAL 9001
X02
reseda green
RAL 6011
X03
pebble grey
RAL 7032
X04
sky blue
RAL 5015
X05
light ivory
RAL 1015
X06
white aluminum
RAL 9006
X08
anthracite gray
RAL 7016
X09
1)
Only up to shaft height 100
2)
Connector size M58, cannot be rotated. A terminal box can only be selected as an
alternative up to connector size M58.
3)
For motors with forced ventilation IP54 or IP55
4)
More detailed
information is provided in Chapter "Special options (Page 80)" and in
the associated Chapter "SIMOTICS Servomotors" in Catalog D 21.4
(https://support.industry.siemens.com/cs/document/109747019/)
5)
Only for 1FT7117 motors
6)
Additional colors can be found in Chapter "
Special options (Page 80)" and in the as-
sociated Chapter "SIMOTICS Servomotors" in Catalog D 21.4
(https://support.industry.siemens.com/cs/document/109747019/)
