Connection of stepper drives (e.g. FM STEPDRIVE) to the onboard drive interface (C230-2, C240)
The figure below shows the connection of the C230-2, C240 to FM STEPDRIVE drive units.
$[LV $[LV
$[LV
&RQQHFWLQJFDEOH
$[LV
&&
6,(0(166,(0(16
)067(3'5,9(
6,(0(16


;
; ;
;;
;
6,(0(16
;
&
05(6
6723
581
Figure 5-10 Connection of FM STEPDRIVE drive units
Procedure:
1. Insert the Sub-D socket (15-pin) in the FM STEPDRIVE module.
2. Open the front cover of the C230-2/C240 and connect the Sub-D socket (50-pin) to the
X2 connector.
3. Lock the connector using the finger screws. Close the front cover.
