3.6 Onboard measuring system interface (C230-2, C240)
SIMOTION C
52 Operating Instructions, 02/2012
3.6 Onboard measuring system interface (C230-2, C240)
Connectors to the encoder
A 15-pin Sub-D socket for the connection of incremental or absolute encoders (SSI) is
provided for each axis.
With the C240, this interface (X3 to X6) can also be used as a counter input.
Position of connectors
This figure shows the mounting position and the designation of the connector on the module.
(1&2'(5
(1&2'(5
;;
;
; ;
;;
;
;'303,;'3
&
6,(0(16
;
05(6
6723
581
Figure 3-8 Position of connectors X3 to X6
