Configuring and installing
4.3 Installing
SIMOTION C
Operating Instructions, 02/2012
87
4.3.2 Fitting modules on the mounting rail
Accessories
Any accessories you need for installation are in the pack with the modules. Chapter Spare
parts and accessories (Page 184) contains a list of accessorie
s and spare parts together
with the corresponding order numbers.
Table 4- 6 Module accessories
Module Accessories supplied Explanation
SIMOTION C One slot number plate For the assignment of slot numbers
Two keys (C230-2) The key is used to operate the mode selector
for the C230-2.
One labeling plate For labeling of integrated inputs and outputs
of the SIMOTION C
Signal module
(SM)
One bus connector To provide the electrical connections between
the modules
One labeling plate To label the inputs and outputs on the module
Sequence in which modules are affixed to the mounting rail
1. Power supply module
2. SIMOTION C
3. Signal module(s)
Installation sequence
The individual steps for the installation of the modules are described below:
1. Except for the SIMOTION C, each signal module is supplied with a bus connector. When
plugging in the bus connectors, always start with the SIMOTION C.
Take the bus connector from the next module and plug it into the bus connector of the
SIMOTION C. (The bus connector is located on the rear side, see Figure "Position of
interfaces and front panel elements").
You must not plug a bus connector into the "last" module in the row.
2. Fit the modules by hooking them into position, push them against the left-hand module
and lower them down into position.
3. Screw down the modules, applying a torque of 0.8 to 1.1 Nm.
