Commissioning
7.2 Inserting and changing the Micro Memory Card
SIMOTION C
Operating Instructions, 02/2012
145
7.2 Inserting and changing the Micro Memory Card
Procedure:
1. Switch off the power supply module.
2. Is a micro memory card inserted? If yes: remove the memory card.
An ejector is located on the frame of the module receptacle to enable you to remove the
micro memory card.
Press the ejector and remove the micro memory card.
3. Applying slight pressure, insert the ("new") micro memory card into the slot of the
SIMOTION C until it snaps into place. Make sure the beveled edge of the micro memory
card faces the ejector (see the following figure).
4. Switch the power supply module on again.
(MHFWRUIRU
PLFURPHPRU\FDUG
Figure 7-1 Inserting the micro memory card into the SIMOTION C
Note
With the SIMOTION C240 / C240 PN, the micro memory card must always be inserted
for operation.
For the purpose of data backup, the contents of the micro memory card can be copied to
the hard drive of a PG/PC with an MMC card reader.
