Siemens SIMOTION C230-2

Alarm, error, and system messages
9.2 Combinations of LED displays
SIMOTION C
170 Operating Instructions, 02/2012
Meaning LED displays
SF
(red)
5 VDC
(green)
RUN
(green)
STOPU
(yellow)
STOP
(yellow)
BUS1F
(red)
BUS2F
(red)
Formatting the micro memory card x 1 0 ☆ 2/1 x x
Request for memory reset by the SIMOTION C
or via the mode selector of the SIMOTION C
x 1 0 0 0,5/1 x x
Memory reset in progress 1 1 1 1 1 1 1
Memory reset complete x 1 0 0 1 x x
SIMOTION Kernel update is running
(SIMOTION C230-2 only)
→ 1 → → → → →
SIMOTION Kernel update is complete
(SIMOTION C230-2 only)
x 1 0 0 1 x x
SIMOTION C240 without micro memory card 1 1 0 1 1 1 1
Copy SIMOTION Kernel to micro memory card 0,5/1 1 0,5/1 0,5/1 0,5/1 0,5/1 0,5/1
SIMOTION C is operating without error. 0 1 x x x 0 0
An interrupt that can be acknowledged (alarm,
message, note) is pending
1 1 x x x x x
Fault to which the user program cannot
respond.
The following actions may be required to rectify
the fault:
 Power OFF/ON
 Check micro memory card
 New commissioning procedure
 Replacement of SIMOTION C
x 1 x ☆ ☆ ☆ ☆
No license exists for technology/optional
objects under license
0,5/1 1 x x x x x
SIMOTION - HOLD status
User program is running at the break point
x 1 0,5/1 1 1 x x
PROFIBUS DP interface as slave
Bus fault
Searching for baud rate
x 1 x x x 1 1
Parameterization error
No cyclic data exchange
x 1 x x x 0,5/1 0,5/1
Cyclic data exchange x 1 x x x 0 0
PROFIBUS DP interface as master
Bus fault (bus short-circuit) x 1 x x x 1 1
Bus fault (slaves have failed or cable faulty) x 1 x x x 0,5/1 0,5/1
No fault or no interface configured x 1 x x x 0 0
