Technical data
10.1 Technical data
SIMOTION C
172 Operating Instructions, 02/2012
DP slave connections
Table 10- 3 Number of DP slave connections
Number of DP slave connections Max. 64
PROFINET device connections
Table 10- 4 Number of PROFINET device connections
Number of PROFINET device connections Max. 64
Address areas
Table 10- 5 Address areas
Input address area, total
2 Kbytes for C230-2
4 Kbytes for C240 / C240 PN
Output address area, total
2 Kbytes for C230-2
4 Kbytes for C240 / C240 PN
Process image inputs 64 bytes
Process image outputs 64 bytes
Connection values
Table 10- 6 Connection values
Supply voltage 24 V DC (permissible range: 20.4 to 28.8 V)
Power consumption from 24 V
typically 0.9 A (inputs/outputs open)
typically 1.2 A (with 4 encoders, 5 V)
typically 1.9 A (with 4 encoders, 24 V)
Power loss 15 W
Starting current 8 A
Encoder supply 5 V max. output current 1.2 A
Encoder supply 24 V max. output current 1.2 A
Dimensions and weight
Table 10- 7 Dimensions and weight
Dimensions W x H x D [mm] 200 x 125 x 118
Weight [g] Approximately 1,150
