Technical data
10.4 Mechanical and climatic environmental conditions for operation of the SIMOTION C
SIMOTION C
Operating Instructions, 02/2012
181
Climatic environmental conditions
The SIMOTION C may be used under the following climatic environmental conditions:
Table 10- 17 Climatic environmental conditions
Environmental conditions Range of application Comments
Temperature:
Horizontal mounting:
Vertical mounting
From 0 to 55° C
From 0 to 40° C
-
Relative humidity From 5% to 95% Without condensation,
corresponds to relative humidity
(RH) severity level 2 in
accordance with IEC 1131-2
Atmospheric pressure 1,060 to 700 hPa Corresponds to an altitude of
mean sea level to 3,000 m
Contaminant concentration
SO
2
: < 0.5 ppm;
Relative humidity <60%,
no condensation
H
2
S: < 0.1 ppm;
Relative humidity <60%,
no condensation
Test:
10 ppm; 4 days
1 ppm; 4 days
Moisture condensation and
ice formation
Not permitted
Mechanical environmental conditions
The mechanical environmental conditions for the SIMOTION C are specified in the following
table in terms of sinusoidal vibrations.
Table 10- 18 Mechanical environmental conditions
Mechanical environmental
conditions
Operation Transport (in packaging)
Vibration tested in
accordance with DIN EN
60068-2-68
10 to 58 Hz: 0.35 mm
58 to 200 Hz: 50 m/s
2
5 to 9 Hz: 3.5 mm
9 to 200 Hz: 10 m/s
2
Shock resistance tested in
accordance with
DIN EN 60068-2-27
10 g peak value, 6 ms duration
100 shocks in each of the 3 axes
vertical to one another
10 g peak value, 6 ms duration
100 shocks in each of the 3 axes
vertical to one another
Reduction of vibration
If the SIMOTION C is subjected to greater shocks or vibrations, you must take appropriate
measures to reduce the acceleration or the amplitude.
Installation on damping material (e.g. rubber-bonded metals) is recommended.
