Description
1.9 CompactFlash card
SIMOTION D4x5
Manual, 02/2012
31
Available Z options / licenses for CompactFlash Cards
● Axis licenses
– Pxx POS license and number (e.g. P02 = 2x POS license)
– Gxx GEAR license and number (e.g. G03 = 3 x GEAR licenses)
– Cxx CAM license and number (e.g. C01 = 1x CAM license)
● MultiAxes Package
– M00 MultiAxes Package license (platform independent)
– M42-MultiAxes Package license for D425
– M43-MultiAxes Package license for D435 (incl. D425)
– M44-MultiAxes Package license for D445/D445-1 (incl. D425 and D435)
● MultiAxes and SAFETY INTEGRATED EXTENDED Package
– S42/S43/S44 license as M42/M43/M44 license, but also including licensing of the
Safety Integrated Extended Functions for all drives on SINAMICS Integrated/CX32
● TControl temperature control
– Txx TControl license and number (e.g. T03 = 3x TControl licenses)
● SIMOTION IT
– D00 - SIMOTION IT DIAG license (no longer under license as of SIMOTION V4.2)
– X00 - SIMOTION IT OPC XML-DA license (no longer under license as of SIMOTION
V4.2)
– J00 - SIMOTION IT Virtual Machine license for Java applications
● Safety functions
– Fxx-License for SINAMICS Safety Integrated Extended Functions (for integrated
SINAMICS drives for SIMOTION D4x5 and CX32) (e.g. F02=2x Safety Integrated
Extended Functions).
Note
CompactFlash Cards provided as part of a MultiAxes bundle do not have this additional
labeling option. Depending on the version, a MultiAxes bundle consists of a SIMOTION
D425, D435 or D445/D445-1 plus a CompactFlash Card with a "MultiAxes Package" license
for the relevant SIMOTION D hardware.
