Supplementary system components
6.4 Controller Extension CX32
SIMOTION D4x5
98 Manual, 02/2012
6.4.5 Commissioning
Note
Information about commissioning can be found in the
SIMOTION D4x5
Commissioning and
Hardware Installation Manual.
6.4.6 Technical data
Memory for system data
Table 6- 20 Diagnostics buffer
Data SIMOTION CX32
Diagnostics buffer (protected against power
failure)
100 messages
The data for the CX32 is stored exclusively on the SIMOTION D435/D445/D445-1, which
means no action has be taken when the module is replaced.
Dimensions and weight
Table 6- 21 Dimensions and weight of a SIMOTION CX32
Parameter SIMOTION CX32
Dimensions W x H x D [mm]
(max. expansion)
• Without fastening using spacers
• With fastening using spacers
• 25 x 380 x 230
• 25 x 380 x 270
Weight CX32 [g]
• Without packaging
• With packaging
• approx. 2200
• approx. 2700
