Supplementary system components
6.3 TB30 terminal board
SIMOTION D4x5
Manual, 02/2012
87
6.3.3.6 Working with analog inputs
The following reference contains more information about analog inputs:
● /IH1/
SINAMICS S120
Commissioning Manual.
● /GH1/
SINAMICS S120
Control Units and Additional System Components Manual.
6.3.3.7 Commissioning
Information about commissioning can be found in the
SIMOTION D4x5
Commissioning and Hardware Installation Manual.
6.3.4 Technical Specifications
Table 6- 9 Technical data of the TB30
Unit Value
Electronic power supply:
- Voltage
- Current via the option slot of the
D4x5
(without digital outputs)
- Power loss
V
DC
A
DC
W
24 (20.4 ... 28.8)
0.05
<3
Response time The response time of digital inputs/outputs and analog inputs/outputs depends on
the evaluation on the Control Unit (see function diagram).
Reference: SINAMICS S120/S150 Parameter Manual, Chapter "Function
diagrams"
Dimensions (H x W x D), approx. mm 25 x 95 x 143
Weight g 100
