Supplementary system components
6.4 Controller Extension CX32
SIMOTION D4x5
Manual, 02/2012
91
6.4.2.1 List of interfaces
The CX32 has the following interfaces:
● 4 DRIVE-CLiQ interfaces
● 4 digital inputs/outputs
● 4 digital inputs
● Power supply connector
Available interfaces
Table 6- 12 Overview of available interfaces
Interface Name Connector type
DRIVE-CLiQ interface X100 DRIVE-CLiQ socket
DRIVE-CLiQ interface X101 DRIVE-CLiQ socket
DRIVE-CLiQ interface X102 DRIVE-CLiQ socket
DRIVE-CLiQ interface X103 DRIVE-CLiQ socket
Digital inputs/outputs X122 Micro Combicon, 1x12-pin
Power supply connector X124 Combicon, 4-pin
Measuring sockets (T0, T1, T2, and M) X131 - X134 Sockets
Non-usable interfaces
Table 6- 13 Overview of interfaces that cannot be used for the CX32
Interface name Interface Connector type
RS 232 interface (as of HW version B) X140 9-pin Sub-D connector
