Interfaces
3.6 PROFIBUS DP interfaces
SIMOTION D4x5
52 Manual, 02/2012
3.6 PROFIBUS DP interfaces
Features of the interface
Table 3- 12 Interfaces X126 and X136
Features Type
Connector type 9-pin SUB-D socket
Cable type PROFIBUS cable
Maximum cable length 100 m at 12 Mbps
Interface assignment for X126
Table 3- 13 PROFIBUS DP interface X126
Pin Signal name Signal type Meaning
1 -- -- Reserved, do not use
2 G VO Ground to P24_SERV
3 1RS_DP B RS-485 differential signal
4 1RTS_DP O Request to send
5 1G VO Ground to 1P5
6 1P5 VO 5 V power supply for bus terminal, external, short-circuit
proof
7 P24_SERV VO 24 V for teleservice, short-circuit proof, 150 mA maximum
8 1XRS_DP B RS-485 differential signal
9 -- -- Reserved, do not use
The 1P5 voltage is provided exclusively for the bus terminal.
No OLPs are permitted.
Signal type: VO = Voltage output (power supply) O = Output B = Bidirectional
