3.4 Digital inputs/digital outputs
SIMOTION D4x5
48 Manual, 02/2012
Interface assignment of X122 and X132
Table 3- 8 Digital inputs/outputs X122
Pin Designation
1)
Signal type
2)
Notes
1 DI 0 I Digital input 0
2 DI 1 I Digital input 1
3 DI 2 I Digital input 2
4 DI 3 I Digital input 3
5 G1 GND Ground for DI 0 – DI 3 (electrically isolated relative to G)
6 G GND Ground
7 DI/DO 8 B Digital input/digital output 8 (can be used as a high-speed
output of an output cam/DO)
8 DI/DO 9 B Digital input/digital output 9 (can be used as a high-speed
input of a measuring input or output of an output cam/DO)
9 G GND Ground
10 DI/DO 10 B Digital input/digital output 10 (can be used as a high-
speed input of a measuring input or output of an output
cam/DO)
11 DI/DO 11 B Digital input/digital output 11 (can be used as a high-
speed input of a measuring input or output of an output
cam/DO)
12 G GND Ground
1)
DI: digital input; DI/DO: bidirectional digital input/output; G or GND: Electronics ground;
G1: Ground reference
2)
B = Bidirectional; I = Input; GND = Reference potential (ground)
Table 3- 9 Digital inputs/outputs X132
Pin Designation
1)
Signal type
2)
Notes
1 DI 4 I Digital input 4
2 DI 5 I Digital input 5
3 DI 6 I Digital input 6
4 DI 7 I Digital input 7
5 G2 GND Ground for DI 4 – DI 7 (electrically isolated relative to G)
6 G GND Ground
7 DI/DO 12 B Digital input/digital output 12 (can be used as a high-
speed output of an output cam/DO)
8 DI/DO 13 B Digital input/digital output 13 (can be used as a high-
speed input of a measuring input or output of an output
cam/DO)
9 G GND Ground
10 DI/DO 14 B Digital input/digital output 14 (can be used as a high-
speed input of a measuring input or output of an output
cam/DO)
