Siemens SIMOTION CX32 User Manual

Supplementary system components
6.3 TB30 terminal board
SIMOTION D4x5
Manual, 02/2012
85
Table 6- 6 X481 wiring
Characteristics Type
Connectable cable types:
• Rigid
• Flexible
• Flexible, with wire-end ferrule without plastic
sleeve
• AWG / kcmil
Conductor cross-sections:
• 0.14 mm
2
to 0.5 mm
2
• 0.14 mm
2
to 0.5 mm
2
• 0.25 mm
2
to 0.5 mm
2
• 26 to 20
Stripped length 8 to 9 mm
Tool Screwdriver 0.4 x 2.0 mm
Note
An open input is interpreted as "low".
The power supply and the digital inputs/outputs are isolated from the Control Unit.
Note
With momentary interruptions in the 24 V supply, the digital outputs are deactivated during
this time.
