Description
1.2 System components
SIMOTION D410-2
Manual, 02/2012
15
Component Function
SIMATIC ET 200pro Modular I/O system with IP65/IP67 rating for machine-related applications with no control
cabinet; with new features such as more compact designs, integrated PROFIsafe safety
technology, PROFINET connection and live module replacement.
SIMATIC ET 200eco I/O system with IP65/IP67 rating for machine-related applications with no control cabinet,
with a flexible and fast connection system in ECOFAST or M12.
Other PROFIBUS I/O
Gateways
• DP/AS-Interface Link 20E and DP/AS-Interface Link Advanced for the PROFIBUS DP
gateway to AS-Interface
• DP/DP coupler to connect two PROFIBUS DP networks
Drive interfaces
• ADI4 (Analog Drive Interface for 4 axes) for the connection of drives with analog ±10 V
setpoint interface or for external encoders
• IM 174 (Interface Module for 4 axes) for the connection of drives with analog ±10 V
setpoint interface, external encoders or the connection of stepper drives with
pulse/direction interface
Teleservice adapter Remote diagnostics
Ethernet
The control unit can communicate with the following components via the Ethernet interfaces
or be embedded in an automation environment:
Table 1- 3 Components on the Ethernet
Component Function
Programming device (PG/PC) ... configures, sets parameters, programs and tests using the SIMOTION SCOUT
Engineering System (ES).
Master computer ... communicates with other devices via UDP, TCP/IP.
SIMATIC HMI device ... is used for operator control and monitoring functions. This is not an essential
requirement for the operation of the SIMOTION D410-2.
