• Humidity
• Strong magnetic elds
Use prohibition
Without additional measures, SIMOTION D410-2 must not be used in
• Locations with a high percentage of ionizing radiation
• Locations with extreme operating conditions, e.g.
– Dust accumulation
– Corrosive vapors or gases
• Installations requiring special monitoring such as:
– Elevator installations
– Electrical systems in particularly hazardous rooms
An additional measure for using SIMOTION D410-2 can, for example, be installation in cabinets.
Note
The components must be protected against conductive contamination, e.g. by installing them
in a control cabinet with degree of protection IP54 according to IEC 60529 or NEMA 12.
If conductive contamination can be excluded at the installation site, a lower degree of cabinet
protection may be permitted.
See Industrial security.
Ambient operating conditions for the operation
SIMOTION D410-2 can be used under the following ambient conditions:
Table 5-2 Environmental requirements
Ambient conditions Fields of application Remarks
Climatic ambient conditions
Climate class 3K3 According to EN 60721‑3:1995
Ambient conditions better than 3K3
Permissible ambient temperature 0 to +55° C, up to 2000 m above sea
level
As of an altitude of 2000 m, the maximum ambi‐
ent temperature decreases by 7 °C every 1000 m
increase in altitude.
Maximum installation altitude 2000 m to max. 4000 m above sea
level
Relative humidity 5 to 95%
Condensation, icing, drip, spray and
splash water
Not permissible
Atmospheric pressure 620 to 1060 hPa Corresponding height 4000 m ‑ 0 m above sea
level.
Mechanical ambient conditions
Technical data
5.2 Ambient conditions
SIMOTION D410-2
82 Equipment Manual, 07/2021, A5E33446720B
