Ambient conditions Fields of application Remarks
Pollution degree 2 according to EN 60664‑1:2008
Biological ambient conditions: Class 3B1 according to
EN 60721‑3‑3:1995
Mold, mold growth, slime, rodents, termites and
other animal vermin are not permissible
Chemically active environmental
conditions
Class 3C1 according to
EN 60721‑3‑3:1995
Mechanically active environmental
conditions
Class 3S1 according to
EN 60721‑3‑3:1995
Conductive dusts are not permitted.
Vibratory load
- D410-2
- S120 (without SME/DME)
Vibratory load during operation ac‐
cording to EN 60721-3-3: Class 3M1
Test values according to EN 60068-2-6 (sinusoi‐
dal)
• 10 ... 57 Hz: 0.075 mm de󹪞ection amplitude
• 57 ... 150 Hz: 1 g acceleration amplitude
• 10 frequency cycles per axis
Shock load
- D410-2
- S120 (without SME/DME)
Shock load during operation accord‐
ing to EN 60721-3-3: Class 3M1
Test values according to EN 60068-2-27 (half-si‐
nusoidal)
• 5 g peak acceleration, 30 ms duration
• 3 shocks in all three axes in both directions
Note
Observe the 󹪝elds of application of the Power Modules along with their derating. Refer
to SINAMICS S120 for AC Drives Manual.
Vibration reduction
If SIMOTION D410-2 is subjected to larger shocks or vibrations, you must use suitable measures
to reduce the acceleration or the amplitude.
We recommend installation on shock-absorbing material (e.g. rubber-metal vibration dampers).
Other data
Condition Field of application
Protection against the ingress of for‐
eign matter and water
IP20 degree of protection according to EN 60529
Class of protection Class 1 (with protective conductor system) and class 3 (PELV) ac‐
cording to EN 61800‑5‑1:2007
Technical data
5.2 Ambient conditions
SIMOTION D410-2
Equipment Manual, 07/2021, A5E33446720B 83
