Siemens Simovert 6SE70 Series User Manual

09.02 Start-Up
Siemens AG 6SE7087-6AK85-1AA0
4-29
Rectifier/Regenerating Unit Operating Instructions
4.3.1.4 Actual values
All available parameter numbers (0 to 999) can be entered into the actual value parameters, sorted according to
destinations (refer to the following).
The parameter value of the entered parameter number is output at the selected destination.
Note
: - When specifying parameter numbers, which are indexed, the value of the first index (.i001) is always
output!
- When specifying "0", no output is made to the appropriate destination!
Destinations:
P655 "CUR-AA actual values"
Output via the CUR control terminal strip (Section 3.3)
Analog output 1 (-X102:14 / reference potential -X102:15)
(refer to Section 4.3.5 "analog output")
P680 "SST1 actual values"
Output via the basic converter interface SST1
Indices: i001 Word 01 of the telegram (PZD)
⇓ ⇓
i016 Word 16 of the telegram (PZD)
(refer to Section 4.3.6.1 "basic converter interface SST1")
Destination, options:
P664 "SCI-AA actual values"
Output via the SCB1 interface with SCI1
(also refer to the Instruction Manual for the option boards)
Indexes i001 Destination: Analog output 1 from slave 1
i002 Destination: Analog output 2 from slave 1
i003 Destination: Analog output 3 from slave 1
i004 Destination: Analog output 1 from slave 2
i005 Destination: Analog output 2 from slave 2
i006 Destination: Analog output 3 from slave 2
P690 "SCB actual values"
Output via the SCB1 interface with peer-to-peer protocol or SCB2
(also refer to the Instruction Manual for the option boards)
Indexes: i001 Destination: Word 01 of the telegram (PZD)
⇓ ⇓
i016 Destination: Word 16 of the telegram (PZD)
P694 "CB/TB actual values"
Output via the CB or TB interface
(also refer to the Instruction Manual for the option boards and Sections 4.3.6.2 "DPR")
Indices: i001 Destination: Word 01 of the telegram (PZD)
⇓ ⇓
i016 Destination: Word 16 of the telegram (PZD)
NOTE
For telegram data transfer (P680,P690,P694), it is generally necessary/practical to assign "Word 01 of the
telegram (PZD)" with status word 1 (r968 or r552)!
