Siemens Simovert 6SE70 Series User Manual

Start-Up 09.02
4-14 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating Instructions
4.3.1.1.3 Selecting the source for control word 1 (bit 0-7)
Bit
0 1 2 3 4 5 6 7
Selection P. basic setting 554.1 555 to 557.1 561.1 565 to 567.1
Selection P. reserve setting 554.2 555 to 557.2 561.2 565 to 567.2
Value Source
0000 Constant value = 0
x x
xG/R
0001 Constant value = 1
xG/R xG/
R
1001 CUR, BE1, -X101:9
xR
x
x x
1002 CUR, BE2, -X101:10 x
xR for 555
x x
1003 CUR, BE3, -X101:11 x x x
xR for 565
1004 CUR, BE4, -X101:12 x x x x
1005 CUR, BE5, -X101:13 x x x x
1010 PMU
xG xG for 555
1)
2001 SST1 (PMU -X300 or
-X100:1...5) Word1
x x x
xG/R for 567
2004 SST1 (PMU -X300 or
-X100:1...5) Word4
OPTIONS
3001 CB/TB (Word1) x x x x
3004 CB/TB (Word4)
4101 SCI 1 and 2, Slave 1,BE1 x x x x
4102 BE2 x x x x
... Consecutively to x x x x
4110 BE10 x x x x
4111 only SCI 2, Slave 1,BE11 x x x x
4112 BE12 x x x x
... Consecutively to x x x x
4116 BE16 x x x x
4201 SCI 1 and 2, Slave 2,BE1 x x x x
4202 BE2 x x x x
... Consecutively to x x x x
4210 BE10 x x x x
4211 only SCI 2, Slave 2,BE11 x x x x
4212 BE12 x x x x
... Consecutively to x x x x
4216 BE16 x x x x
4501 SCB-SST (USS /Peer-t-Peer) Word1 x x x x
4504 SCB-SST (USS /Peer-t-Peer) Word4
6001 SST2 (PTP1, A2-X117:1..5) Word 1 x x x x
... Consecutively to x x x x
6005 SST2 (PTP1, A2-X117:1..5) Word 5 x x x x
x: Value can be assigned for the selection parameters (BE can only be assigned once in the same index
of all selection parameters!)
1) Value 1010 cannot be set, but reset is always
possible from PMU.
Factory setting: xG: for basic setting with P077=0
xR: for reserve setting with P077=0
