Siemens Simovert 6SE70 Series User Manual

09.02 Parameter List
Siemens AG 6SE7087-6AK85-1AA0
5-21
Rectifier/Regenerating Unit Operating Instructions
PNU
* : Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
P575
*
Src No ExtFault1
Source for the "External fault 1" control command (control word 1, bit 15)
L signal causes disconnection of the faulted drive.
0: Not allowed
1: No external fault 1
1003: Binary input 3 of the CUR board
Other values:
see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
B/R parameter
PNU=23FHex; Type=L2; Scaling: 1Hex
=
∧
1
1 to 6005 2
(1)
2/ BR
2/ BR
P578
*
Src RDataSetBit0
Source for bit 0 (control word 2, bit 18) for selecting the reserve data set
(RDS)
0: RDS bit 0 has the value 0
1: RDS bit 0 has the value 1
Other values:
see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
B/R parameter
PNU=242Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
0
3/ BR
3/ BR
P579
*
Src RDataSetBit1
Source for bit 1 (control word 2, bit 19) for selecting the reserve data set
(RDS)
0: RDS bit 1 has the value 0
1: RDS bit 1 has the value 1
Other values:
see allowed settings in section 4.3.1.1 (process data
wiring of the control word)
B/R parameter
PNU=243Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
0
2/ BR
2/ BR
P583
*
Src 12-Pulse Mode
Source for control command "12-pulse mode is selected" (control word 2, bit
23)
0: No 12-pulse mode
1: 12-pulse mode is selected
Other values: see allowed settings in section 4.3.1.1 (process data
wiring of the control word)
B/R parameter
PNU=247Hex; Type=L2; Scaling: 1Hex
=
∧
1
1 to 6005 2
(0)
3/ BR
3/ BR
P586
*
Src No ExtFault2
Source of the 'External fault 2' message (control word 2, bit 26)
L signal causes disconnection of the faulted unit after a pre-charging time of
+ 200ms if the rectifier/regenerating unit is in the "RUN" status.
0: Not allowed
1: No external fault
1004: Binary input 4 of the CUR board
Other values: see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
B/R parameter
PNU=24AHex; Type=L2; Scaling: 1Hex
=
∧
1
1 to 6005 2
1
2/ BR
2/ BR
