Siemens Simovert 6SE70 Series User Manual

Parameter List 09.02
5-24 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating Instructions
PNU
* : Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
P607
*
Trg Bit Warning
Destination of the status bit 'Warning' (status word 1, bit 7)
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=25FHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
(0)
2/ BR
2/ BR
P608
*
Trg Bit Deviat.
Destination wiring of the status bit "U
d
set = U
d
act“ (status word 1, bit 8) -
cf. P517
Parameter values, indices: as P600
PNU=260Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P610
*
Trg Regen Ready
Destination wiring of the status bit "Regenerating ready" (status word 1,
Bit 10)
Parameter values, indices: as P600
PNU=260Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P611
*
Trg Low Voltage
Destination of the status bit 'Undervoltage' (status word 1, bit 11)
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=263Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P612
*
Trg Bit Contact
Destination of the status bit 'Energize main contactor' (status word 1, bit 12)
H level: energize contactor!
Important: Relay X9-4/5, whose function cannot be programmed, is
provided for controlling the main contactor.
Parameter values, indices: as P600
PNU=264Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
P613
*
Trg DC V reduced
Destination wiring for the status bit "U
d
reduced“
(status word 1, bit 13)
Parameter values, indices: as P600
PNU=265Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ ABR
3/ ABR
P614
*
**
Trg Motor/Regen
Destination wiring for the status bit "Regenerative/motoring mode" (status
word 1, bit 14)
Parameter values, Indices: as P600
PNU=266Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 4212 2
0
3/ BR
3/ BR
