Siemens Simovert 6SE70 Series User Manual

Parameter List 09.02
5-28 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating Instructions
PNU
* : Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
P661 SCI AnaInSmooth
Filter time constant of the SCI analog inputs
i001: Sl11 Slave 1, analog input 1
i002: Sl12 Slave 1, analog input 2
i003: Sl13 Slave 1, analog input 3
i004: Sl21 Slave 2, analog input 1
i005: Sl22 Slave 2, analog input 2
i006: Sl23 Slave 2, analog input 3
PNU=295Hex; Type=O2; Scaling: 1Hex
=
∧
1
0 to 15 6
2
3/ BR
3/ BR
P662 SCI AnalogInOffs
Offset scaling of the SCI analog inputs
Description for setting see SCI manual
i001: Sl11 Slave 1, analog input 1
i002: Sl12 Slave 1, analog input 2
i003: Sl13 Slave 1, analog input 3
i004: Sl21 Slave 2, analog input 1
i005: Sl22 Slave 2, analog input 2
i006: Sl23 Slave 2, analog input 3
PNU=296Hex; Type=I2; Scaling: 1Hex
=
∧
0.01 V
-320.00 to 320.00
[V]
6
0.00
3/ BR
3/ BR
P664 SCI AnaOutActVal
Actual value output via SCI analog outputs
Description for setting:
Enter the parameter number of the quantities, which are to be issued; for
details see SCI manual.
i001: Sl11 Slave 1, analog output 1
i002: Sl12 Slave 1, analog output 2
i003: Sl13 Slave 1, analog output 3
i004: Sl21 Slave 2, analog output 1
i005: Sl22 Slave 2, analog output 2
i006: Sl23 Slave 2, analog output 3
Condition:
The related SCB board must be reported via P090 and P091, respectively
PNU=298Hex; Type=O2; Scaling: 1Hex
=
∧
1
0 to 999 6
0
3/ BR
3/ BR
P665 SCI AnaOut Gain
Proportional gain of the SCI analog outputs
Description for setting: see SCI manual
i001: Sl11 Slave 1, analog output 1
i002: Sl12 Slave 1, analog output 2
i003: Sl13 Slave 1, analog output 3
i004: Sl21 Slave 2, analog output 1
i005: Sl22 Slave 2, analog output 2
i006: Sl23 Slave 2, analog output 3
PNU=299Hex; Type=I2; Scaling: 1Hex
=
∧
0.01 V
-320.00 to 320.00
[V]
6
10.00
3/ BR
3/ BR
P666 SCI AnaOut Offs
Offset of the SCI analog outputs
i001: Sl11 Slave 1, analog output 1
i002: Sl12 Slave 1, analog output 2
i003: Sl13 Slave 1, analog output 3
i004: Sl21 Slave 2, analog output 1
i005: Sl22 Slave 2, analog output 2
i006: Sl23 Slave 2, analog output 3
PNU=29AHex; Type=I2; Scaling: 1Hex
=
∧
0.01 V
-320.00 to 320.00
[V]
6
0.00
3/ BR
3/ BR
