Siemens SINAMICS S120 - 1 FK7 High Dynamic Motors

Motor Description
1.3 Selection and Ordering Data
Synchronous Motors 1FK7
20 Configuration Manual, (PFK7S), Edition 12.2006, 6SN1197-0AD16-0BP1
1.3.2 1FK7 High Dynamic motors
To select the degree of protection and type, see “Selection guide”.
Rated
speed
Shaft
height
Rated
power
Static
torque
Rated
torque
1)
Rated current 1FK7 High Dynamic
synchronous motor
with natural cooling
Num-
ber of
pole
pairs
Rotor
moment of
inertia
(without
brake)
Weight
(without
brake)
n
rated
SH P
rated
at
∆
T=100 K
M
0
at
∆
T=100 K
M
rated
at
∆
T=100 K
I
rated
at
∆
T=100 K
Order No. J m
rpm kW/HP Nm/lb
f
-ft Nm/lb
f
-ft A
10
-4
kgm
2
/
lb
f
-in-s
2
kg/lb
3000 48 1.1/1.48 4/2.9 3.5/2.6 4 1FK7044-7AF71-1 777 3 1.28/0.0011 7.7/17
63
1.7/2.28
2.51/3.37
6.4/4.7
12/8.8
5.4/4
8/5.9
5.3
7.5
1FK7061-7AF71-1 777
1FK7064-7AF71-1 777
3
3
3.4/0.0030
6.5/0.0058
10/22.1
15.5/34.2
80
3.14/4.21
2)
3.77/5.06
3)
22/89.9
28/20.6
12/8.8
2)
18/13.3
3)
12.5
2)
14.5
3)
1FK7085-7AF71-1 777
1FK7086-7AF71-1 777
4
4
23/0.0204
23/0.0204
23.5/51.8
23.5/51.8
4500 48 1.23/1.65
1.41/1.89
3.1/2.3
4/2.9
2.6/1.9
3/2.2
4
4.9
1FK7043-7AH71-1 777
1FK7044-7AH71-1 777
3
3
1/0.0009
1.28/0.0011
6.3/13.9
7.7/17
63
2.03/2.72
2.36/3.16
6.4/4.7
12/8.8
4.3/3.2
5/3.7
5.9
7
1FK7061-7AH71-1 777
1FK7064-7AH71-1 777
3
3
3.4/0.0030
6.5/0.0058
10/22.1
15.5/34.2
6000 36 0.57/0.76 1.3/1 0.9/0.7 1.5 1FK7033-7AK71-1 777 3 0.27/0.0002 3.1/6.8
48
1.26/1.69 3.1/2.3 2/1.5 4.4 1FK7043-7AK71-1 777 3 1/0.0009 6.3/13.9
Encoder systems for motors
without DRIVE-CLiQ interface:
Incremental encoder sin/cos 1 V
pp
2048 pulses/revolution
Absolute encoder EnDat 2048 pulses/revolution
1)
(not for 1FK703)
Absolute encoder EnDat 512 pulses/revolution
1)
(only for 1FK703)
Basic absolute encoder EnDat 32 pulses/rev.
1)
(not for 1FK703)
Multi-pole resolver
2-pole resolver
A
E
H
G
S
T
Encoder systems for motors
mit DRIVE-CLiQ-Schnittstelle:
Incremental encoder sin/cos 1 V
pp
2048 pulses/revolution
Absolute encoder EnDat 2048 pulses/rev.
1)
(not for 1FK703)
Absolute encoder EnDat 512 pulses/revolution
1)
(only for 1FK703)
Basic absolute encoder EnDat 32 pulses/rev.
1)
(not for 1FK703)
Multi-pole resolver
2-pole resolver
D
F
L
K
U
P
Shaft extension:
Fitted key and keyway
Fitted key and keyway
Plain shaft
Plain shaft
Radial eccentricity
tolerance:
N
N
N
N
Holding brake:
without
with
without
with
A
B
G
H
Degree of protection: IP64
IP65 and IP67 drive end flange
IP64, anthracite paint finish
IP65 and drive end flange IP67, anthracite paint finish
0
2
3
5
