Application
2.1 Environment
Synchronous Motors 1FK7
Configuration Manual, (PFK7S), Edition 12.2006, 6SN1197-0AD16-0BP1
29
Routing cables in a wet/moist environment
Notice
If the motor is mounted in a humid environment, the power and signal cables must be routed
as shown in the following figure.
6,(0(16
6,(0(16
6,(0(16
6,(0(16
6,(0(16
6,(0(16
ULFKWLJ
SHUPLWWHG
QLFKWHUODXEW
QRWSHUPLWWHG
Figure 2-2 Routing cables in a wet/moist environment
2.1.5 Paint finish
1FK7 motors are supplied without a paint finish (1FK701 with paint finish).
Option: with anthracite finish (similar to RAL 7016)
Note
The motors must be ordered with a special paint finish if they are to be used in sub-tropical
regions or if they are to be transported by sea. This paint finish prevents the stator lamination
from corroding.
