Parameter request Offset
1st parameter ad‐
dress
Attribute = 10 hex Number of elements = 01 hex 4 + 5
Parameter no. = 1055 dec 6
Subindex = 0 dec 8
2nd parameter ad‐
dress
Attribute = 10 hex Number of elements = 01 hex 10 + 11
Parameter no. = 1056 dec 12
Subindex = 0 dec 14
3rd parameter ad‐
dress
Attribute = 10 hex Number of elements = 01 hex 16 + 17
Parameter no. = 1058 dec 18
Subindex = 0 dec 20
4th parameter ad‐
dress
Attribute = 10 hex Number of elements = 01 hex 22 + 23
Parameter no. = 1059 dec 24
Subindex = 0 dec 26
1st parameter val‐
ue(s)
Format = 07 hex Number of values = 01 hex 28 + 29
Value = 02D2 hex 30
Value = 0404 hex 32
2nd parameter val‐
ue(s)
Format = 07 hex Number of values = 01 hex 34 + 35
Value = 02D2 hex 36
Value = 0405 hex 38
3rd parameter val‐
ue(s)
Format = 08 hex Number of values = 01 hex 40 + 41
Value = 4396 hex 42
Value = 0000 hex 44
4th parameter val‐
ue(s)
Format = 08 hex Number of values = 01 hex 46 + 47
Value = 4416 hex 48
Value = 0000 hex 50
Notes relating to the parameter request:
● Request reference:
The value is selected at random from the valid value range. The request reference
establishes the relationship between request and response.
● Request ID:
02 hex → This identifier is required for a write request.
● Axis:
02 hex → The parameters are written to drive 2.
● Number of parameters
04 hex → The multi-parameter request comprises four individual parameter requests.
1st parameter address ... 4. Parameter address
● Attribute:
10 hex → The parameter values are to be written.
● Number of elements
01 hex → One array element is written.
Communication
A.1 Communication
Industrial Security
104 Configuration Manual, 08/2017, A5E36912609A
