Bit 7 6 5 4 3 2 1 0
Octet Name
... ...
x Bit
structure
... ... KB_n+1 KB_n ... ... ... ...
Status messages/module status
Status messages and module status briefly represent an overview of the state of the devices:
Bit 7 6 5 4 3 2 1 0
Octet Name
1 Header
byte
0 0 Block length (2 ... 32) incl. this byte
2 Module
status
0x82
3 Slot 0
4 Specifier 0
5 Slot_4 Slot_3 Slot_2 Slot_1
6 ... Slot_7 Slot_6 Slot_5
... ...
x 00 Slot_n ... ...
Note
Status value
Diagnostics for SINAMICS are only available in cyclic PROFIBUS operation, so that the state
00 = "Valid useful data" is always output for all slots.
Communication
A.1 Communication
