Table A-33 Instance Attribute
No. Service Type Name Value/explanation
1 get UINT16 Vendor ID 1251
2 get UINT16 Device Type
- Siemens Drive 0C hex
3 get UINT16 Product code r0964[1]
4 get UINT16 Revision ‑
5 get UINT16 Status See the following table
6 get UINT32 Serial number Bit 0 … 19: consecutive number;
bits 20 … 23: Production identifier
bits 24 … 27: Month of manufacture (0 = Jan, B =
Dec)
Bits 28 … 31: Year of manufacture (0 = 2002)
7 get Short
String
Product name max. length 32 byte
Table A-34 Explanation for No. 5 of the previous table
Byte Bit Name Description
1 0 Owned 0: Converter is not assigned to a controller
1: Converter is assigned to a controller
1 ‑ Reserved
2 Configured 0: Ethernet/IP basic settings
1: Modified Ethernet/IP settings
3 ‑ Reserved
4 … 7 Extended De‐
vice Status
0: Self-test or status not known
1: Firmware update active
2: At least one I/O connection with error
3: No I/O connections
4: Incorrect configuration in the ROM
5: Fatal fault
6: At least one I/O connection is active
7: All I/O connections in the quiescent state
8 … 15: Reserved
2 8 … 11 ‑ Not used
12 … 15 ‑ Reserved
Assembly Object, Instance Number: 4 hex
Supported services
Class ● Get Attribute single Instance ● Get Attribute single
● Set Attribute single
Communication
A.1 Communication
Industrial Security
Configuration Manual, 08/2017, A5E36912609A 193
