No. Service Type Name Value/explanation
5 get,
get_and_
clear
Struct of Media Counters Media-specific counters
UINT32 Alignment Errors Structure received, which does not match the num‐
ber of octets
UINT32 FCS Errors Structure received, which does not pass the FCS
check
UINT32 Single Collisions Structure successfully transmitted, precisely one col‐
lision
UINT32 Multiple Colli‐
sions
Structure successfully transmitted, several collisions
UINT32 SQE Test Errors Number of SQE errors
UINT32 Deferred Trans‐
missions
First transmission attempt delayed
UINT32 Late Collisions Number of collisions that occurred delayed by 512
bit timers to the request
UINT32 Excessive Colli‐
sions
Transmission unsuccessful as a result of intensive
collisions
UINT32 MAC Transmit Er‐
rors
Transmission unsuccessful as a result of an internal
MAC sublayer transmission error.
UINT32 Carrier Sense Er‐
rors
Number of errors when attempting to send a request
frame, where the transmission condition was lost or
was not assigned
UINT32 Frame Too Long Structure too large
UINT32 MAC Receive Er‐
rors
Transmission unsuccessful as a result of an internal
MAC sublayer receive error.
6 get, set Struct of Interface Control ‑
UINT16 Control Bits ‑
UINT16 Forced Interface
Speed
‑
10 get String Interface_Label Interface-Label
11 get ‑ Interface Capabil‐
ity
Bit 0: Manual Setting
Bit 1: Auto-negotiate
Bit 2: Auto-MDIX
Bit 3: Manual Speed/Duplex
Bit 4 - 31: reserved
Remaining: Speed/Duplex Options
Parameter Object, Instance Number: 401 hex
Supported services
Class ● Get Attribute all Instance ● Get Attribute all
● Set Attribute single
