SINUMERIK 801 Control System
1-4 SINUMERIK 801
Start-Up
Acknowledge alarm
Delete key (backspace)
SPACE (INSERT)
Vertical menu
ENTER / input key
Shift key
…
Numerical keys (with shift for
alternative assignment)
…
Alphanumeric keys (with shift for
alternative assignment)
Notice
See”Operation & Programming” for the use of NC keys.
MCP (Machine Control Panel) area
Chuck clamping (with LED)
Spindle override 100％
Chuck clamping internally / Chuck clamping
externally (with LED)
Spindle override minus (with LED)
Chuck unclamping (with LED)
X axis, plus direction
Manual tool change (with LED)
X axis, minus direction
Manual lubrication (with LED)
Z axis, plus direction
Manual coolant (with LED)
Z axis, minus direction
AUTOMATIC (with LED)
RAPID TRAVERSE OVERLAY
SINGLE BLOCK (with LED)
SPINDLE START LEFT
Counterclockwise direction
MANUAL DATA (with LED)
SPINDLE STOP
Increment (with LED)
SPINDLE START RIGHT
Clockwise direction
