SINUMERIK 801 Control System
1-6 SINUMERIK 801
Start-Up
1.3 Position of the Interfaces
General Interfaces of the control system are positioned in the rear of the CNC system,
see Fig. 1-3 below.
Interfaces Interfaces of the SINUMERIK 801 control system are shown as below:
Fig. 1-3 Position of SINUMERIK 801 interfaces
Notice
See Section 2.3 “Interfaces and Cables” for detailed description of each
interface.
