Built-In PLC Application
3-10 SINUMERIK 801
Start-Up
3.4 Fixed PLC Alarms
Definition of fixed PLC alarms
Table 3-6 Definition of fixed PLC alarms
Alarm # Alarm Description
700008 Turret # wrongly defined, MD14510[4] (4/6)
700009 Turret clamping time undefined, check MD14510[6]
700010 Turret monitoring time undefined, check MD14510[5]
700011 Spindle brake time out range, check MD14510[7]
700021 Spindle/feed axis start impossible while unclamped
700022
Unclamping impossible while spindle run or NC start enabled in
AUTO or MDA mode
700023 Programmed tool #. > Max. turret on turret#
700024 Tool not found, monitoring time up
700025 No position signals from turret
700027 Approach ref. point again after rot. monitoring
