Siemens SINUMERIK 802C User Manual

Technical Appendix
6.2 PLC user interface signals
6-109
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
Feed override
2)
32000004
H G F E D C B A
Rapid traverse override
3)
32000005
H G F E D C B A
Feed
1)
Rapid tra- Program Delete Read–in Feed
32000006
override
enabled
verse
override
level
abortion
distance
to go
disabled lock
enabled override
enabled
abortion to go
NC stop NC stop
32000007 axes plus NC stop to block NC start NC start
spindle limit inhibited
Notes:
1)
+ Feed override enabled Even if the feed override is not enabled (=100%), the 0% position is active.
2)
+ Feed override 31 positions (Gray code) with 31 MD for % weighting
3)
+ Rapid traverse override 31 positions (Gray code) with 31 MD for % weighting
4)
+ Single Block Use the softkey to select Single Block Type Preselection (SBL1/SBL2) see ”User Manual”
Control signals to axes in the WCS
3200 Signals to NCK Channel [r/w]
Data block
Interface PLC –––––> NCK
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Axis 1 in WCS
32001000 Traversing keys
Rapid
traverse
Traversing
key
Feed Activate handwheel
+ –
override
lock stop 2 1
Axis 1 in WCS
32001001 Machine function
continu-
ous
1000 INC 100 INC 10 INC 1 INC
32001002
32001003
Axis 2 in WCS
32001004 Traversing keys
Rapid
traverse
Traversing
key lock
Feed Activate handwheel
+ –
override
Stop 2 1
Axis 2 in WCS
32001005 Machine function
continu-
ous
1000 INC 100 INC 10 INC 1 INC
32001006
32001007
