Siemens SINUMERIK 802C User Manual

Technical Appendix
6.1 List of machine and setting data
6-103
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
36300
ENC_FREQ_LIMIT
Hz Encoder limit frequency POWER ON
_always 300000 0 plus DOUBLE 2/7
36302
ENC_FREQ_LIMIT_LOW
% Encoder limit frequency at which encoder is switched on again. (Hysteresis) NEW CONF
_always 99.9 0 100 DOUBLE 2/7
36310
ENC_ZERO_MONITORING
- Zero mark monitoring (encoder no.): 0,1
0: Zero mark monitoring off, encoder HW monitoring on
1-99, >100: Number of recognized zero mark errors during monitoring
100: Zero mark monitoring off, encoder HW monitoring off
NEW CONF
_always 0, 0 0.0 plus DWORD 2/7
36400
CONTOU_TOL
mm, deg. Contour monitoring tolerance band NEW CONF
_always 1.0 *** *** DOUBLE 2/2
36500
ENC_CHANGE_TOL
mm, deg Portion of distance for backlash working NEW CONF
_always 0,1 0.0 plus DOUBLE 2/7
36610
AX_EMERGENCY_STOP_TIME
s Duration of the deceleration ramp for error states NEW CONF
_always 0.05 0.0 plus DOUBLE 2/7
36620
SERVO_DISABLE_DELAY_TIME
s Cutout delay servo enable NEW CONF
_always 0.1 0.0 plus DOUBLE 2/7
36700
DRIFT_ENABLE
- Automatic drift compensation NEW CONF
_always 0 *** *** BOOLEAN 2/7
36710
DRIFT_LIMIT
% Drift limit value for automatic drift compensation NEW CONF
_always 1.000 0.0 plus DOUBLE 2/7
36720
DRIFT_VALUE
% Drift basic value NEW CONF
_always 0.0 DOUBLE 2/7
38000
MM_ENC_COMP_MAX_POINTS
- Number of intermediate points for interpolatory compensation (SRAM) POWER ON
_always 0, 0 0 5000 DWORD 2/7
6.1.5 Setting data
Number MD Name
Unit Name, Miscellaneous Activated
HW / function Standard value Minimum value Maximum value D type User
class
41110
JOG_SET_VELO
mm/min Axis speed for JOG Immediately
_always 0.0 0.0 plus DOUBLE 4/4
41200
JOG_SPIND_SET_VELO
rev/min Speed for spindle JOG mode Immediately
_always 0.0 0.0 plus DOUBLE 4/4
