7.8 I/O assignment in the standard PLC program
7-132
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
7.8.2 Assignment of the digital outputs:
1st module:
O 0.0 X2005 Pin 2 DO 0
O 0.1 Pulse enable drive I/RF module X2005 Pin 3 DO 1
O 0.2 Pulse enable drive X2005 Pin 4 DO 2
O 0.3 Coolant pump ON X2005 Pin 5 DO 3
O 0.4 Secondary power ON X2005 Pin 6 DO 4
O 0.5 Fault general X2005 Pin 7 DO 5
O 0.6 Fault lubrication X2005 Pin 8 DO 6
O 0.7 X2005 Pin 9 DO 7
O 1.0 Ready X2006 Pin 2 DO 8
O 1.1 X2006 Pin 3 DO 9
O 1.2 X2006 Pin 4 DO 10
O 1.3 Lubrication axes X2006 Pin 5 DO 11
O 1.4 X2006 Pin 6 DO 12
O 1.5 X2006 Pin 7 DO 13
O 1.6 X2006 Pin 8 DO 14
O 1.7 X2006 Pin 9 DO 15
2nd module:
O 2.0 Spindle contactor (control) X2005 Pin 2 DO 0
O 2.1 X2005 Pin 3 DO 1
O 2.2 Bypass axis limit switch X2005 Pin 4 DO 2
O 2.3 X2005 Pin 5 DO 3
O 2.4 X2005 Pin 6 DO 4
O 2.5 X2005 Pin 7 DO 5
O 2.6 X2005 Pin 8 DO 6
O 2.7 X2005 Pin 9 DO 7
O 3.0 X2006 Pin 2 DO 8
O 3.1 X2006 Pin 3 DO 9
O 3.2 X2006 Pin 4 DO 10
O 3.3 X2006 Pin 5 DO 11
O 3.4 X2006 Pin 6 DO 12
O 3.5 X2006 Pin 7 DO 13
O 3.6 X2006 Pin 8 DO 14
O 3.7 X2006 Pin 9 DO 15
