Siemens SINUMERIK 802C User Manual

Technical Appendix
6.2 PLC user interface signals
6-119
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
L6 L5 L4 L3 L2 L1
11000000
11000001
6.2.8 PLC machine data
INT values (MD 14510
USER_DATA_INT)
4500 Signals from NCK [r]
Data block
Interface NCK –––––> PLC
Byte
45000000 Int value (WORD/ 2 bytes)
45000002 Int value (WORD/ 2 bytes)
45000004 Int value (WORD/ 2 bytes)
45000006 Int value (WORD/ 2 bytes)
45000060 Int value (WORD/ 2 bytes)
45000062 Int value (WORD/ 2 bytes)
HEX values (MD 14512 USER_DATA_HEX)
4500 Signals from NCK [r]
Data block
Interface NCK –––––> PLC
Byte
45001000 Hex value (BYTE)
45001001 Hex value (BYTE)
45001002 Hex value (BYTE)
45001003 Hex value (BYTE)
45001030 Hex value (BYTE)
45001031 Hex value (BYTE)
