1.2 Technical data
1-12
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
1.2 Technical data
Connected load
Table 1-1 Connected load
Parameter
Min. Typ. Max. Unit
Supply voltage 20.4 28.8 V
Ripple 3.6 Vss
Current consumption from 24 V 1 A *
Power dissipation of ENC
Power dissipation of OP020
Power dissipation of MCP
Power dissipation of DI/O16
15
7
-
7
W
W
W
**
Start–up current 2.6 A
* Basic configuration of ENC,
OP020, MCP and DI/O16, all
outputs open,
current consumption for any
further DI/O16 connected
will increase by 0.05 A each.
** at nominal load
Weight
Table 1-2 Weight
Component
Weight [g]
ENC component 900 g
DI/O16 component 350 g
OP020 component 1,800 g
MCP component 1,200 g
Dimensions
Table 1-3 Component dimensions
Component
Dimensions HxWxD [mm]
ENC component 125 x 200 x 118
DI/O component 125 x 80 x 118
OP020 component 300 x 250 x 50
MCP component 300 x 170 x 50
