Siemens SINUMERIK 802C User Manual

Technical Appendix
6.1 List of machine and setting data
6-102
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
35440 SPIND_OSCILL_TIME_CW
s Reciprocation time for M3 direction NEW CONF
_always 1.0 0.0 plus DOUBLE 2/7
35450 SPIND_OSCILL_TIME_CCW
s Reciprocation time for M4 direction NEW CONF
_always 0.5 0.0 plus DOUBLE 2/7
35510
SPIND_STOPPED_AT_IPO_START
- Feedrate enable for spindle stopped RESET
_always 0 *** *** BOOLEAN 2/7
36000
STOP_LIMIT_COARSE
mm, deg. Exact positioning coarse NEW CONF
_always 0.04 0.0 plus DOUBLE 2/7
36010
STOP_LIMIT_FINE
mm, deg. Exact positioning fine NEW CONF
_always 0.01 0.0 plus DOUBLE 2/7
36020
POSITIONING_TIME
s Delay exact positioning fine NEW CONF
_always 1.0 0.0 plus DOUBLE 2/7
36030
STANDSTILL_POS_TOL
mm, deg. Zero-speed tolerance NEW CONF
_always 0.2 0.0 plus DOUBLE 2/7
36040
STANDSTILL_DELAY_TIME
s Delay zero-speed monitoring NEW CONF
_always 0.4 0.0 plus DOUBLE 2/7
36050
CLAMP_POS_TOL
mm, deg. Clamping tolerance NEW CONF
_always 0.5 0.0 plus DOUBLE 2/7
36060
STANDSTILL_VELO_TOL
mm/min,
rev/min
Maximum velocity/speed ”axis/spindle stopped” NEW CONF
_always 5 (0.014) 0.0 plus DOUBLE 2/7
36100
POS_LIMIT_MINUS
mm, deg. 1st software limit switch minus RESET
_always -100000000 - - DOUBLE 2/7
36110
POS_LIMIT_PLUS
mm, deg. 1st software limit switch plus RESET
_always 100000000 - - DOUBLE 2/7
36120
POS_LIMIT_MINUS2
mm, deg. 2nd software limit switch minus RESET
_always -100000000 - - DOUBLE 2/7
36130
POS_LIMIT_PLUS2
mm, deg. 2nd software limit switch plus RESET
_always 100000000 - - DOUBLE 2/7
36200
AX_VELO_LIMIT
mm/min,
rev/min
Threshold value for velocity monitoring
(control parameter set no.): 0...5
NEW CONF
_always 11500., 11500., 11500.,
11500., ...
0.0 plus DOUBLE 2/7
