Technical Appendix
6.1 List of machine and setting data
6-101
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
35120
GEAR_STEP_MIN_VELO
rev/min Minimum speed for gear change (gear stage no.): 0..5 NEW CONF
_always 50, 50, 400, 800, 1500, 3000 0.0 plus DOUBLE 2/7
35130
GEAR_STEP_MAX_VELO_LIMIT
rev/min Maximum speed of gear stage (gear stage no.): 0...5 NEW CONF
_always 500, 500, 1000, 2000, 4000,
8000
0.0 plus DOUBLE 2/7
35140
GEAR_STEP_MIN_VELO_LIMIT
rev/min Minimum speed of gearsetp (gear stage no.): 0...5 NEW CONF
_always 5, 5,10, 20, 40, 80 0.0 plus DOUBLE 2/7
35150
SPIND_DES_VELO_TOL
Factor Spindle speed tolerance RESET
_always 0.1 0.0 1.0 DOUBLE 2/7
35160
SPIND_EXTERN_VELO_LIMIT
rev/min Spindle speed limitation from PLC NEW CONF
_always 1000 0.0 plus DOUBLE 2/7
35200
GEAR_STEP_SPEEDCTRL_ACCEL
rev/s^2 Acceleration in speed control mode [gear stage no.]: 0...5 NEW CONF
_always 30, 30, 25, 20, 15, 10 2 *** DOUBLE 2/7
35210
GEAR_STEP_POSCTRL_ACCEL
rev/s^2 Acceleration in position control mode (gear stage no.): 1...5 NEW CONF
_always 30, 30, 25, 20, 15, 10 2 *** DOUBLE 2/7
35220
ACCEL_REDUCTION_SPEED_POINT
Factor Speed for reduced acceleration RESET
_always 1.0 0.0 1.0 DOUBLE 2/7
35230
ACCEL_REDUCTION_FACTOR
Factor Reduced acceleration RESET
_always 0.0 0.0 0.95 DOUBLE 2/7
35240
ACCEL_TYPE_DRIVE
- Type of acceleration RESET
0 0 1 BOOLEAN 2/7
35300
SPIND_POSCTRL_VELO
rev/min Position control switch-on speed NEW CONF
_always 500 0.0 plus DOUBLE 2/7
35350
SPIND_POSITIONING_DIR
- Direction of rotation when positioning RESET
_always 3 3 4 BYTE 2/7
35400 SPIND_OSCILL_DES_VELO
rev/min Reciprocation speed NEW CONF
_always 500 0.0 plus DOUBLE 2/7
35410 SPIND_OSCILL_ACCEL
rev/s^2 Acceleration during reciprocating NEW CONF
_always 16 2 *** DOUBLE 2/7
35430 SPIND_OSCILL_START_DIR
– Starting direction during reciprocation
0–2: As last direction of rotation (zero–speed M3)
3: M3 direction
4: M4 direction
RESET
_always 0 0 4 BYTE 2/7
