Siemens SINUMERIK 802C User Manual

Technical Appendix
6.1 List of machine and setting data
6-100
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
34040
REFP_VELO_SEARCH_MARKER
mm/min,
rev/min
Creep speed (encoder no.) RESET
_always 300.0 0.0 plus DOUBLE 2/7
34050
REFP_SEARCH_MARKER_REVERSE
- Direction reversal to reference cams (encoder no.) RESET
_always 0 *** *** BOOLEAN 2/7
34060
REFP_MAX_MARKER_DIST
mm, deg. Maximum distance to reference mark. Max. distance to 2 reference marks
for distance-coded measuring systems.
RESET
_always 20.0 0.0 plus DOUBLE 2/7
34070
REFP_VELO_POS
mm/min,
rev/min
Reference point positioning velocity RESET
_always 1000.0 0.0 plus DOUBLE 2/7
34080
REFP_MOVE_DIST
mm, deg. Reference point distance/target point for distance-coded system RESET
_always -2.0 - - DOUBLE 2/7
34090
REFP_MOVE_DIST_CORR
mm, deg. Reference point offset/absolute offset distance-coded POWER ON
_always 0.0 - - DOUBLE 2/7
34092
REFP_CAM_SHIFT
mm, deg. Electr. cam offset of incremental measuring systems with equidistant zero marks RESET
_always 0.0 0.0 plus DOUBLE 2/7
34100
REFP_SET_POS
mm, deg. Reference point value/irrelevant for distance-coded system: 0 ... 3 RESET
_always 0., 0., 0., 0. - - DOUBLE 2/7
34110
REFP_CYCLE_NR
- Sequence of axes in channel-specific referencing
-1: No obligatory reference point for NC Start
0: No channel-specific reference-point approach
1-15: Sequence in channel-specific reference point approach
RESET
_always 1 -1 31 DWORD 2/7
34200
ENC_REFP_MODE
- Type of position measuring system
0: No ref. point appr.; if an absolute encoder exists: REFP_SET_POS accepted
1: Zero pulse (on encoder track)
POWER ON
_always 1 0 6 BYTE 2/7
35010
GEAR_STEP_CHANGE_ENABLE
- Gear change possible. Spindle has several gear steps POWER ON
_always 0 *** *** BOOLEAN 2/7
35040
SPIND_ACTIVE_AFTER_RESET
- Own spindle reset POWER ON
_always 0 *** *** BOOLEAN 2/7
35100
SPIND_VELO_LIMIT
rev/min Maximum spindle speed POWER ON
_always 10000 0.0 plus DOUBLE 2/7
35110
GEAR_STEP_MAX_VELO
rev/min Maximum speed for gear change (gear stage no.): 0..5 NEW CONF
_always 500, 500, 1000, 2000, 4000,
8000
0.0 plus DOUBLE 2/7
