Siemens SINUMERIK 802C User Manual

Installing the Control System
2.3 Connecting the individual components
2-32
SINUMERIK 802C
6FC5 597–3AA20–0BP2 (01.02)
Table 2-15 Connector pin assignment
X2003
Pin Name Type
1
2 DI0 I
3 DI1 I
4 DI2 I
5 DI3 I
6 DI4 I
7 DI5 I
8 DI6 I
9 DI7 I
10 M24 V
X2004
Pin Name Type
1
2 DI8 I
3 DI9 I
4 DI10 I
5 DI11 I
6 DI12 I
7 DI13 I
8 DI14 I
9 DI15 I
10 M24 V
Signal names
DI0...15 24 V digital inputs
Signal type
V Voltage input
I Input (24 V signal)
